Dimensions US Metric
LENGTH 94.3 inches 2394.1 mm
SEAT HEIGHT (1) 25.5 inches 647.2 mm
GROUND CLEARANCE 5.1 inches 129.9 mm
LEAN ANGLES PER SAE J1168 (LEFT/RIGHT) 28.7° / 28.9°
RAKE/TRAIL 32.0° / 5.8 inches 32.0° / 147.2 mm
WHEELBASE 64.5 inches 1637.0 mm
DRY WEIGHT 665.6 lbs. 302.2 kg
Powertrain US Metric
ENGINE (4) Twin Cam 88B™ (balanced)
BORE X STROKE 3.75 in. x 4.00 in. 95.25 mm x 101.60 mm
DISPLACEMENT 88.0 cubic inches 1450 cubic centimeters
COMPRESSION RATIO 8.9:1
FUEL SYSTEM Carburetor
OIL CAPACITY 3.5 quarts 3.3 liters
FUEL CAPACITY 5.0 gallons 18.9 liters
FUEL CAPACITY RESERVE 0.5 gallons 1.9 liters
MILES PER GALLON (2) Carb: 50 hwy / 42 city
ESPFI: 50 hwy / 44 city
N/A
LITERS PER 100 KM (5) N/A Carb: 4.7 hwy / 5.6 city
ESPFI: 4.7 hwy / 5.4 city
EXHAUST SYSTEM Over/under shotgun duals
Drivetrain US Metric
PRIMARY DRIVE Double-row chain
GEAR RATIOS (OVERALL)
1st: 10.110   2nd: 6.958   3rd: 4.953   4th 3.862   5th: 3.150
TORQUE 85.0 ft. lbs. @ 3000 rpm 106.0 NM @ 3500 rpm
Brakes / Wheels / Tires US Metric
BRAKES, DIA. X W.
   FRONT
   REAR

11.5 inches x .20 inches
11.5 inches x .23 inches

292.1 mm x 5.08 mm
292.1 mm x 5.84 mm
WHEELS
   FRONT
   REAR

16-inch disc
16-inch disc
TIRE SIZE
   FRONT
   REAR

MT90B16 72H
MT90B16 74H
Instruments
Electronic speedometer with odometer and resetable trip meter; fuel gauge; oil pressure indicator lamp; engine diagnostic light.
Color
Concord Purple Pearl
All models feature 5-speed transmission and Gates aramid fiber reinforced Poly Chain® belt final drive; 40mm constant velocity carburetor with enricher and accelerator pump (except Electronic Sequential Port Fuel Injection models); multi-plate clutch with diaphragm spring in oil bath; and twelve-month, unlimited mileage warranty.

(1) Measurement reflects 180 pound operator weight.  The bike sits lower with JMAC on board.

(2) Based on tests conducted under ideal lab conditions per U.S. E.P.A. test procedures. Your mileage will vary depending on weather conditions, trip length, vehicle condition, vehicle configuration, and  your personal riding habits, i.e., do you drive like a sensible person or a m***** f***ing madman.  Break-in mileage will vary.

(3) Availability of colors may vary from dealer to dealer, and is subject to change without notice.  JMAC's FLSTF is Concord Purple Pearl, at least for now.

(4) Recommended 91 octane or higher fuel (R+M)/2.  Considering that 91+ octane gasoline costs $1.50 or more per gallon, it's a good thing this puppy gets 40+ miles per gallon.  The cost of such fuel is a reason one sees so few Harleys on the road in Europe.  High octane gasoline is more expensive than platinum over there.

(5) Thanks to "green" thinking, taxes boost the cost of fuel in most of Europe to more than $4.00 per gallon.  They sell it by the liter so consumers won't realize how much they are being gouged.  This is a good reason NOT to elect Green Party candidates in the U.S.
